Descrizione
Gli inverter di stringa trifase della serie BNT di Afore sono progettati per applicazioni di impianti fotovoltaici residenziali e commerciali di piccole dimensioni, con potenze da 3kW a 25kW. Tutti i modelli sono dotati di alloggiamenti unibody con struttura in alluminio anodizzato, che ne aumenta la durata e previene efficacemente la corrosione. Dotati di induttori esterni, gli alloggiamenti unibody possono garantire un’efficiente dissipazione del calore, che migliora significativamente l’affidabilità e prolunga la vita degli inverter.
Le comunicazioni avvengono tramite il modulo Wi-Fi (che può essere sostituito da Ethernet/GPRS). Controllare lo stato del sistema in qualsiasi momento e ovunque tramite il portale online o l’APP.
Interruzione rapida del circuito di guasto ad arco (opzionale)
Protezioni multiple intelligenti
Compatibile con i moduli bifacciali
Monitoraggio del livello delle stringhe
Introduzione al prodotto
Intervallo MPPT
Ampio intervallo MPPT
PV sovradimensionato
1,5 volte il sovradimensionamento PV
Corrente continua 1100 V
Max. CC 1100 V
UNIBODY
Alloggiamento monoblocco in alluminio
PROTEZIONE
SPD integrato di tipo II
SMART
Scansione intelligente della curva IV
AGGIORNAMENTO
Aggiornamento firmware remoto
| Technical Data | BNT003KTL | BNT004KTL | BNT005KTL | BNT006KTL | BNT008KTL | BNT010KTL |
|---|---|---|---|---|---|---|
| PV Input Data | ||||||
| Max.DC Power(W) | 5100 | 6000 | 7500 | 9000 | 12000 | 15000 |
| Max. DC Voltage (V) | 1100 | 1100 | 1100 | 1100 | 1100 | 1100 |
| MPPT Voltage Range (V) | 150-1000 | 150-1000 | 150-1000 | 150-1000 | 150-1000 | 150-1000 |
| MPPT Full Power Voltage Range (V) | 200-850 | 200-850 | 200-850 | 250-850 | 300-850 | 500-850 |
| Rated Input Voltage(V) | 620 | 620 | 620 | 620 | 620 | 620 |
| Start-up Voltage(V) | 150 | 150 | 150 | 150 | 150 | 150 |
| Max.Input Current(A) | 15x2 | 15x2 | 15x2 | 15x2 | 15x2 | 15x2 |
| Max.Short Current(A) | 25x2 | 25x2 | 25x2 | 25x2 | 25x2 | 25x2 |
| No.of MPP Tracker/No.of PV String | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 |
| Input Connector Type | MC4 | MC4 | MC4 | MC4 | MC4 | MC4 |
| AC Output Data | ||||||
| Max. Output Power (VA) | 3000 | 4000 | 5000 | 6000 | 8000 | 10000 |
| Nomina Output Power(W) | 3000 | 4000 | 5000 | 6000 | 8000 | 10000 |
| l Max. Output Current (A) | 5.3 | 7 | 8.5 | 10.5 | 13.5 | 17 |
| Nominal Output Voltage(V) | 3P+N+PE/3P+PE 230/400 | 3P+N+PE/3P+PE 230/400 | 3P+N+PE/3P+PE 230/400 | 3P+N+PE/3P+PE 230/400 | 3P+N+PE/3P+PE 230/400 | 3P+N+PE/3P+PE 230/400 |
| Grid Voltage Range | 260Vac-519Vac (according to local standard) | 260Vac-519Vac (according to local standard) | 260Vac-519Vac (according to local standard) | 260Vac-519Vac (according to local standard) | 260Vac-519Vac (according to local standard) | 260Vac-519Vac (according to local standard) |
| Nominal Output Frequency ( Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Grid Frequency Range | 45-55Hz/55-65Hz(according to local standard) | 45-55Hz/55-65Hz(according to local standard) | 45-55Hz/55-65Hz(according to local standard) | 45-55Hz/55-65Hz(according to local standard) | 45-55Hz/55-65Hz(according to local standard) | 45-55Hz/55-65Hz(according to local standard) |
| Output Power Factor | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) |
| Output Current THD | <3% | <3% | <3% | <3% | <3% | <3% |
| Efficiency | ||||||
| Max. Efficiency | 98.30% | 98.30% | 98.30% | 98.30% | 98.30% | 98.70% |
| Euro Efficiency | 97.61% | 97.6 | 98.00% | 98.05% | 98.05% | 98.23% |
| Protection | ||||||
| PV Reverse Polarity Protection | YES | YES | YES | YES | YES | YES |
| PV Insulation Resistance Detection | YES | YES | YES | YES | YES | YES |
| AC Short Circuit Protection | YES | YES | YES | YES | YES | YES |
| AC Over Current Protection | YES | YES | YES | YES | YES | YES |
| AC Over Voltage Protection | YES | YES | YES | YES | YES | YES |
| Anti-Islanding Protection | YES | YES | YES | YES | YES | YES |
| Residual Current Detection | YES | YES | YES | YES | YES | YES |
| Over Temperature Protection | YES | YES | YES | YES | YES | YES |
| Integrated DC switch | YES | YES | YES | YES | YES | YES |
| Surge Protection | Integrated(Type II) | Integrated(Type II) | Integrated(Type II) | Integrated(Type II) | Integrated(Type II) | Integrated(Type II) |
| Smart IV Curve Scaning | YES | YES | YES | YES | YES | YES |
| Quick Arc Fault Circuit Interruption | Optional | Optional | Optional | Optional | Optional | Optional |
| General Data | ||||||
| Dimensions (WxHxD,mm) | 370x510x167 | 370x510x167 | 370x510x167 | 370x510x167 | 370x510x192 | 370x510x192 |
| Weight(kg) | 16 | 16 | 16 | 16 | 16 | 16 |
| Protection Degree | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| Enclosure Material | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum |
| Ambient Temperature Range(℃) | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 |
| Humidity Range | 0-100% | 0-100% | 0-100% | 0-100% | 0-100% | 0-100% |
| Topology | Transformerless | Transformerless | Transformerless | Transformerless | Transformerless | Transformerless |
| Communication Interface | RS485/WiFi/Wire Ethernet/GPRS(optional) | RS485/WiFi/Wire Ethernet/GPRS(optional) | RS485/WiFi/Wire Ethernet/GPRS(optional) | RS485/WiFi/Wire Ethernet/GPRS(optional) | RS485/WiFi/Wire Ethernet/GPRS(optional) | RS485/WiFi/Wire Ethernet/GPRS(optional) |
| Cooling Concept | Convection | Convection | Convection | Convection | Intelligent fan cooling | Intelligent fan cooling |
| Night Power Consumption ( W) | <1 | <1 | <1 | <1 | <1 | <1 |
| Max. Operation Altitude (m) | ≤4000 | ≤4000 | ≤4000 | ≤4000 | ≤4000 | ≤4000 |
| Certifications and Standards | ||||||
| EMC Standard | EN/IEC 61000-6-2, EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2, EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2, EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2, EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2, EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2, EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 |
| Safety Standard | IEC 60068, UL1741, EN62109 | IEC 60068, UL1741, EN62109 | IEC 60068, UL1741, EN62109 | IEC 60068, UL1741, EN62109 | IEC 60068, UL1741, EN62109 | IEC 60068, UL1741, EN62109 |
| Grid-connection | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, |
| Technical Data | BNT012KTL | BNT013KTL | BNT015KTL | BNT017KTL | BNT020KTL | BNT025KTL |
|---|---|---|---|---|---|---|
| PV Input Data | ||||||
| Max.DC Power(W) | 18000 | 19500 | 22500 | 25500 | 30000 | 37500 |
| Max.DC Voltage(V) | 1100 | 1100 | 1100 | 1100 | 1100 | 1100 |
| MPPT Voltage Range (V) | 150-1000 | 150-1000 | 150-1000 | 150-1000 | 150-1000 | 150-1000 |
| MPPT Full Power Voltage Range (V) | 500-850 | 500-850 | 500-850 | 500-850 | 500-850 | 500-850 |
| Rated Input Voltage(V) | 620 | 620 | 620 | 620 | 620 | 620 |
| Start-up Voltage(V) | 150 | 150 | 150 | 150 | 150 | 150 |
| Max.Input Current(A) | 15x2 | 15x2 | 20+32 | 32x2 | 32x2 | 32x2 |
| Max.Short Current(A) | 25x2 | 25x2 | 30+48 | 48x2 | 48x2 | 48x2 |
| No. of MPP Tracker / No.of PV String | 2/2 | 2/2 | 2/3 | 2/4 | 2/4 | 2/4 |
| Input Connector Type | MC4 | MC4 | MC4 | MC4 | MC4 | MC4 |
| AC Output Data | ||||||
| Max.Output Power (VA ) | 12000 | 13000 | 15000 | 17000 | 20000 | 25000 |
| Nominal Output Power (W) | 12000 | 13000 | 15000 | 17000 | 20000 | 25000 |
| Max. Output Current (A) | 21.5 | 22 | 27 | 30 | 32 | 40 |
| Nominal Output Voltage (V) | 3P+N+PE /3P+PE 230/400 | 3P+N+PE /3P+PE 230/400 | 3P+N+PE /3P+PE 230/400 | 3P+N+PE /3P+PE 230/400 | 3P+N+PE /3P+PE 230/400 | 3P+N+PE /3P+PE 230/400 |
| Grid Voltage Range | 260Vac-519Vac (according to local standard) | 260Vac-519Vac (according to local standard) | 260Vac-519Vac (according to local standard) | 260Vac-519Vac (according to local standard) | 260Vac-519Vac (according to local standard) | 260Vac-519Vac (according to local standard) |
| Nominal Output Frequency( Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Grid Frequency Range | 45-55Hz/55-65Hz(according to local standard) | 45-55Hz/55-65Hz(according to local standard) | 45-55Hz/55-65Hz(according to local standard) | 45-55Hz/55-65Hz(according to local standard) | 45-55Hz/55-65Hz(according to local standard) | 45-55Hz/55-65Hz(according to local standard) |
| Output Power Factor | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) |
| Output Current THD | <3% | <3% | <3% | <3% | <3% | <3% |
| Efficiency | ||||||
| Max.Efficiency | 98.70% | 98.70% | 98.70% | 98.75% | 98.75% | 98.75% |
| Euro Efficiency | 98.23% | 98.23% | 98.23% | 98.35% | 98.35% | 98.35% |
| Protection | ||||||
| PV Reverse Polarity Protection | YES | YES | YES | YES | YES | YES |
| PV Insulation Resistance Detection | YES | YES | YES | YES | YES | YES |
| AC Short Circuit Protection | YES | YES | YES | YES | YES | YES |
| AC Over Current Protection | YES | YES | YES | YES | YES | YES |
| AC Over Voltage Protection | YES | YES | YES | YES | YES | YES |
| Anti-Islanding Protection | YES | YES | YES | YES | YES | YES |
| Residual Current Detection | YES | YES | YES | YES | YES | YES |
| Over Temperature Protection | YES | YES | YES | YES | YES | YES |
| Integrated DC switch | YES | YES | YES | YES | YES | YES |
| Surge Protection | Integrated(Type II) | Integrated(Type II) | Integrated(Type II) | Integrated(Type II) | Integrated(Type II) | Integrated(Type II) |
| Smart IV Curve Scaning | YES | YES | YES | YES | YES | YES |
| Quick Arc Fault Circuit Interruption | Optional | Optional | Optional | Optional | Optional | Optional |
| General Data | ||||||
| Dimensions(WxHxD,mm) | 370x510x192 | 370x510x192 | 370x510x192 | 370x535x192 | 370x535x192 | 370x535x192 |
| Weight(kg) | 16 | 17 | 17 | 19 | 19 | 19 |
| Protection Degree | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| Enclosure Material | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum |
| Ambient Temperature Range(℃) | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 |
| Humidity Range | 0-100% | 0-100% | 0-100% | 0-100% | 0-100% | 0-100% |
| Topology | Transformerless | Transformerless | Transformerless | Transformerless | Transformerless | Transformerless |
| Communication Interface | RS485/WiFi/Wire Ethernet/ GPRS (optional) | RS485/WiFi/Wire Ethernet/ GPRS (optional) | RS485/WiFi/Wire Ethernet/ GPRS (optional) | RS485/WiFi/Wire Ethernet/ GPRS (optional) | RS485/WiFi/Wire Ethernet/ GPRS (optional) | RS485/WiFi/Wire Ethernet/ GPRS (optional) |
| Cooling Concept | Intelligent fan cooling | Intelligent fan cooling | Intelligent fan cooling | Intelligent fan cooling | Intelligent fan cooling | Intelligent fan cooling |
| Night Power Consumption( W) | <1 | <1 | <1 | <1 | <1 | <1 |
| Max. Operation Altitude (m) | ≤4000 | ≤4000 | ≤4000 | ≤4000 | ≤4000 | ≤4000 |
| Certifications and Standards | ||||||
| EMC Standard | EN/IEC 61000-6-2,EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3, EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 |
| Safety Standard | IEC 60068, UL1741,EN62109 | IEC 60068, UL1741,EN62109 | IEC 60068, UL1741,EN62109 | IEC 60068, UL1741,EN62109 | IEC 60068, UL1741,EN62109 | IEC 60068, UL1741,EN62109 |
| Grid-connection | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | IEEE1547, CSA C22, EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 |
